Stainless Steel Sheets & Plates

Stainless Steel Sheets & Plates Manufacturers in Mumbai, Stainless Steel Sheets & Plates Suppliers in Mumbai, Stainless Steel Sheets & Plates Stockists in Mumbai, Stainless Steel Sheets & Plates Exporters in Mumbai

Stainless steel sheet is primarily selected for its resistance to corrosion, longevity, and formability. They are uses of stainless steel sheets/plate include construction, food service applications, transportation, chemical, marine, and textile industries. The stainless steel coil is used in the construction and automotive industry for making goods with decorative coatings, they are made from alloys of silicon, nickel, carbon, manganese, and nitrogen. It is wide coils which are typically made at around 1250mm. for example, nitrogen improves tensile properties like ductility, and also Nickel is added to improve its flexibility. Stainless Steel rod grade includes 301, 302, 304, 310, 316, 321/321H, 347/347H Manufacturer.

The stainless steel strip is manufactured from a hot rolled strip that has been preserved, and its grade includes 301, 302, 304, 310, 316, 321/321H, 347/347H Manufacturer. The coil is been reduced by a single stand cold roll steel mill straight away consisting of several single stands in a series. The cold rolling the strip is reduced to approximately final thickness. The final product contains cold-rolled steel that has been cut into strips with specific widths and coiled for delivery. Stainless steel perforated sheet useful for decorative and structural applications, its been manually or mechanically stamped or punched using CNC technology. Its architecture and design, including facades, stairs, balustrades, and screens, and its characteristics allow for creativity with light, sound, and visual depth.

All Chhajed products are manufactured under strict process control and monitored throughout the production process. They go through several checks to ensure that the product delivered is of finest quality!

Specification Schedule of Stainless Steel Sheets & Plates

Description ASTM A240 / ASME SA240 Stainless Steel Plates, ASTM A240 Hot Rolled Stainless Steel Plates
Standard ASTM, ASME, BS, DIN, EN
Material 310S, 310, 309, 309S, 316, 316L, 316Ti, 317, 317L, 321, 321H, 347, 347H, 304, 304L,
302, 301, 201, 202, 403, 405, 409, 409L, 410, 410S, 420, 430, 631, 904L, Duplex, etc
Specification Cold rolled: 1219mm * 2438mm (4′ x 8′), 1219mm * 3048mm (4′ x 10′), 1220mm * 2440mm, 1250mm * 2500mm or as your requirement.>Hot rolled: 1500mm * 2000mm, 1000mm * 3000mm, 1500mm * 4000mm, 1500m * 6000mm or as your requiremnt.
Technique Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Form Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Etc.
Surface 2B, 2D, BA, NO. 1, NO. 4, NO.8, 8K, Mirror, Checkered, Embossed, Hair Line, Sand Blast, Brush, Etching
Thickness 0.25-200mm,  0.3mm to 120mm
Width 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm
Length 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, 12000mm
Package Standard Export Seaworthy Package, or as required.
Value Added Services Cladding,Heat Treatment,Annealed, Pickling, Polish,Rolling,Cutting,Bending,Forging,Minor Fabrication Etc.
 MTC Mill Test Certificate, Available as per EN 10204 3.1

Chemical Properties of Stainless Steel Sheets & Plates

ASTM Grade Carbon Manganese Silicon Sulfur Phospherous Chromium Nickel Molybdenum Other
304 0.08 max 2.00 max 0.75 max 0.030 max 0.045 max 18.0-20.0 8.0 11.0 - -
316 0.08 max 2.00 max 0.75 max 0.030 max 0.045 max 16.0-18.0 10.0 14.0 2.0 3.0 -
317L 0.035 max 2.00 max 0.75 max 0.030 max 0.045 max 18.0-20.0 11.0 14.0 3.0 4.0 -
310 S 0.08 max 2.00 max 1.5 max 0.030 max 0.045 max 24.0-26.0 19.0 22.0 3.0 4.0 -
347 H 0.04 0.10 2.00 max 0.75 max 0.030 max 0.045 max 17.0- 19.0 9.0 13.0 - 10C(Cb+Ta)<1.10%
321 0.08 2.00 max 0.75 max 0.030 max 0.045 max 17.0-20.0 9.0 12.0 - 5C 0.70%

Mechanical Properties of Stainless Steel Sheets & Plates

Grade Elongation Density Tensile Strength Yield Strength (0.2%Offset) Melting Point
SS 202 40 % 8.0 g/cm3 515 MPa 275 MPa 1454 °C (2650 °F)
SS 303 50 % 55% Psi – 85,000 Psi – 45,000 Rb 180
SS 304 40% 8.0 g/cm3 Psi – 75000 , MPa – 515 Psi – 30000 , MPa – 205 1400 °C (2550 °F)
SS 304L 40% 8.0 g/cm3 Psi – 75000 , MPa – 515 Psi – 30000 , MPa – 205 1400 °C (2550 °F)
SS 316 35 % 8.0 g/cm3 Psi – 75000 , MPa – 515 Psi – 30000 , MPa – 205 1454 °C (2650 °F)
SS 316L 40 % 8.0 g/cm3 485 Min 170 Min. 1400 °C (2550 °F)

Equivalent Standard of Stainless Steel Sheets & Plates

UNS NO Outokumpu AISI Werkstoff NO ASTM NO
S31254 254SMO 904L 1.4547 A276
N08904 6Mo (Moly) 1.4539 A479
EN10272 B677
F44

Basic Type of Stainless Steel Sheets & Plates

Stainless Steel Sheets & Plates

Cold Roll AISI Mirror finishing SS Sheet

Stainless Steel Sheets & Plates

4x8 Stainless Steel Sheet

Stainless Steel Sheets & Plates

10mm Thick Stainless Steel Plate

Stainless Steel Sheets & Plates

0.35mm Cold Rolled BA Mirror Secondary Stainless Steel coil

Stainless Steel Sheets & Plates

Cold Rolled SS 1.0mm thick plate

Stainless Steel Sheets & Plates

NO.8 Mirror Stainless Steel Sheet

Stainless Steel Sheets & Plates

Hot Rolled Stainless Steel Plate

Stainless Steel Sheets & Plates

0.8mm Double Color Mirror Stamped Finish SS Sheets

Stainless Steel Sheets & Plates

3mm Thick Stainless Steel Sheet

Stainless Steel Sheets & Plates

Mirror 2B finish 0.6mm 0.5mm SS Sheet

Stainless Steel Sheets & Plates

Hot Rolled 2B Finish 6mm Grade Stainless Steel Sheet

Stainless Steel Sheets & Plates

4mm Cold Rolled Stainless Steel Sheet
