Alloy Steel Sheets & Plates

Alloy Steel Sheets & Plates

Alloy Steel Sheets & Plates Manufacturers in Mumbai, Alloy Steel Sheets & Plates Suppliers in Mumbai, Alloy Steel Sheets & Plates Stockists in Mumbai, Alloy Steel Sheets & Plates Exporters in Mumbai

Alloy Steel Plates Supplier is defined as having 1.5% to 5% total alloy content. Its common alloying elements are manganese, silicon, chromium, nickel, molybdenum, and vanadium, which contain as many as four or five of these alloys in varying amounts. which is been used by the manufacturers who works with petrochemical industries, oil and gas industries, chemical industries, shipbuilding etc. Alloy steel wear plates is a smooth, chromium carbide rich overlay plate manufacturers and Supplier by a patented production process maximizing abrasion resistance and reducing hang up.

Alloy Steel Sheet is been designed from alloys such as chromium, molybdenum, nickel, manganese, silicon so on, they are industrial product that is generally used in various industries applications. 4130 alloy steel sheet is low-alloy steels containing chromium and molybdenum as strengthening agents. It provides good strength and toughness, weldability and machinability. Alloy steel 4340 sheet is a heat treatable low alloy steels which contains nickel, chromium, molybdenum, they are commonly used for heavy duty industrial, aerospace and automotive applications.

It has high strength and toughness in heat treated condition. 6150 alloy steel sheet is useful in heavily stressed machinery parts including gears, shafts, hand tool components and pinions. It is a fine grained, highly abrasion resistant carbon-chromium alloy steel. Alloy Steel Plates Grades are ASTM A387 Gr 5, ASTM A387 Gr 9, ASTM A387 Gr 11, ASTM A387 Gr 12, ASTM A387 Gr 22 and ASTM A387 Gr 91.

All Chhajed products are manufactured under strict process control and monitored throughout the production process. They go through several checks to ensure that the product delivered is of finest quality!

Specification Schedule of Alloy Steel Sheets & Plates

Specifications ASTM A387 / ASME SA387
Thickness 1mm-300mm
Width
 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, 4050mm etc
Length 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, 12000mm, 15000mm etc
Surface 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand
blast, Brush, etching Manufacturer and Supplier
Finish Hot rolled plate (HR), Cold rolled sheet (CR)
Form Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip Manufacturer and Supplier

Chemical Properties of Alloy Steel Sheets & Plates

Grades C Mn P S SI Cr Mo
ASTM A387 Grade 5 0.15 max 0.3 – 0.6 0.035 0.03 0.5 max 4.00 – 6.00 0.45 – 0.65
ASTM A387 Grade 9 0.15 max 0.30 – 0.6 0.03 0.03 1.0 max 8.0 – 10.0 0.9 – 1.1
ASTM A387 Grade 11 0.05 – 0.17 0.4 – 0.65 0.035 0.035 0.5 – 0.80 1.0 – 1.5 0.45 – 0.65
ASTM A387 Grade 12 0.05 – 0.17 0.4 – 0.65 0.035 0.035 0.15 – 0.4 0.8 – 1.15 0.45 – 0.6
ASTM A387 Grade 22 0.05 – 0.15 0.3 – 0.6 0.035 0.035 0.5 max 2.0 – 2.5 0.9 – 1.1

Mechanical Properties of Alloy Steel Sheets & Plates

Tensile Strength Yield Strength Elongationin 200mm (%) Elongation in 50mm (%)
70-90 ksi, 485-620 MPa 45 Ksi, 310 MPa 18 22

Equivalent Standard of Alloy Steel Sheets & Plates

Material Group Common Name Type UNS Forging Spec. Casting Spec. Equivalent DIN DIN W. No Application
Low AS Moly Steel C-1/2Mo K12822 A182-F1 cl2 A217-WC1 15M03 1.5415 Up to 470ºC* (875ºF)
AS Chrome Moly 1.1/4Cr-1/2Mo K11572 A182-F11 cl2 A217-WC6 13CRM044 1.7335 Up to 593ºC (1100ºF)
2.1/4Cr-1Mo K21590 A182-F22 cl3 A217-WC9 10CRM0910 1.7380 Up to 593ºC (1100ºF), HP steam
5Cr-1/2Mo K41545 A182-F5/F5a A217-C5 12CRMO195 1.7362 High temp refinery service
9Cr-1Mo K90941 A182-F9 A217-C12 X 12 CrMo 9 1 1.7386 High temp erosive refinery service
9Cr-1Mo-V A182-F91 A217-C12A X 10 CrMoVNb 9 1 1.4903 High pressure steam

Basic Type of Alloy Steel Sheets & Plates

Alloy Steel Sheets & Plates

Low Alloy Steel Sheets & Plates Stockist

Alloy Steel Sheets & Plates

Chrome Moly Alloy Steel 4340 Plates

Alloy Steel Sheets & Plates

Alloy Steel Wear Plates

Alloy Steel Sheets & Plates

Alloy Steel Sheets

Alloy Steel Sheets & Plates

Alloy Steel 4130 Sheets

Alloy Steel Sheets & Plates

Alloy Steel 4140 Sheets & Plates
