Titanium Grade 2 Sheets & Plates

Titanium Grade 2 Sheets & Plates, Titanium Grade 2 Sheets & Plates Manufacturers, Titanium Grade 2 Sheets & Plates Suppliers, Titanium Grade 2 Sheets & Plates Stockists, Titanium Grade 2 Sheets & Plates Exporters

Titanium Grade 2 Sheets & Plates Manufacturers In India, Titanium Grade 2 Sheets & Plates Suppliers In India, Titanium Grade 2 Sheets & Plates Stockists In India, Titanium Grade 2 Sheets & Plates Exporters In India

Titanium Sheets & Plates

Titanium Grade 2 Sheets & Plates Manufacturers in Mumbai, Titanium Grade 2 Sheets & Plates Suppliers in Mumbai, Titanium Grade 2 Sheets & Plates Stockists in Mumbai, Titanium Grade 2 Sheets & Plates Exporters in Mumbai

Titanium Grade 2 Plate is extensively used in diverse industrial applications, and is formed from the latest technology and superior grade of raw materials, and are commercially pure which contains 99% of minimum titanium. This feature makes it resistant to most oxidizing, neutral, and inhibited reducing, as well as mildly reducing environments. It is corrosion resistance comes from a strong follower, protective oxide feature, stable which forms in the presence of oxygen. Titanium gr 2 plates can be performed using various methods such as TIG and MIG. A mixture of helium and argon is typically preferred but should be tested before accepting a welding procedure. Preheat or post-heat treatments are not needed.

Titanium Grade 2 Sheet corrosion resistance is similar between the four C.P. grades, but mechanical properties differ along with differing iron and oxygen contents. And they provide excellent resistance to marine atmosphere and seawater corrosion. 3.7035 grade 2 sheets can be easily machined, hot worked, and welded. The annealing temperature ranges from 1200°F to 1400°F for 6 minutes to 2 hours accompanied by air cool. Stress relieving should be performed by heating at a temperature range between 900°F to 1100°F followed by either slow cooling or forced air.

All Chhajed products are manufactured under strict process control and monitored throughout the production process. They go through several checks to ensure that the product delivered is of finest quality!

Specification Schedule of Titanium Sheets & Plates

Material	Pure Titanium Grade 2 plate and Ti alloy
Standard	ASTM B265, ASME SB265, AMS 4900, AMS 4901, AMS 4902
Type	Clad Plate, Rolling Plate, Flat Shim, Plain Sheet, Rolling Sheet Rolls, Foils, Coils, Plate, Strip, Sheet, Flats, Blank (Circle), ,Flat Sheet, Shim Sheet, soft annealed, descaled, sheared, annealed, Checker Plate, tread plate Supplier ad manufacturer
Surface	Hot rolled plate (HR), Cold rolled sheet (CR), No.1 finish hot rolled ASTM B265 Ti Plate, BA, No.3, No.4, No.6, No.1, No. 2D, No. 2B, BA NO(8), No.7, 2B, 2D, SATIN (Met with Plastic Coated), 2B, 1D, No.4, 8K, BA, hairline, brush, satin, mirror, Supplier ad manufacturer
Length>	0-12mm or as required
Thickness	0.3 to 1200 mm or as required
Width	0-2500mm or as required
Process	Hot/ Cold Rolled

Chemical Properties of Titanium Sheets & Plates

Grade	Ti	C	Fe	H	N	O	Al	V
Ti Grade 2	99.2 min	0.1 max	0.3 max	0.015 max	0.03 max	0.25 max	–	–

Mechanical Properties of Titanium Sheets & Plates

Element	Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
Titanium Grade 2	4.5 g/cm3	1665 °C (3030 °F)	Psi – 49900 , MPa – 344	Psi – 39900 , MPa – 275	20 %

Equivalent Standard of Titanium Sheets & Plates

STANDARD	WERKSTOFF NR.	UNS
Titanium Grade 2	3.7035	R50400

Basic Type of Titanium Sheets & Plates

Cold Roll AISI Mirror finishing Titanium Grade 2 Alloy Sheet

4x8 Titanium Grade 2 Alloy Sheet

10mm Thick Titanium Grade 2 Alloy Plate

0.35mm Cold Rolled BA Mirror Secondary Titanium Grade 2 Alloy Coil

Cold Rolled Titanium Grade 2 Alloy 1.0mm thick plate

NO.8 Mirror Titanium Grade 2 Alloy Sheet

Hot Rolled Titanium Grade 2 Alloy Plate

0.8mm Double Color Mirror Stamped Finish Titanium Grade 2 Alloy Sheets

3mm Thick Titanium Grade 2 Alloy Sheet

Mirror 2B finish 0.6mm 0.5mm Titanium Grade 2 Alloy Sheet

Hot Rolled 2B Finish 6mm Grade Titanium Grade 2 Alloy Sheet

4mm Cold Rolled Titanium Grade 2 Alloy Sheet
