Hastelloy C276 Sheets & Plates

Hastelloy C276 Sheets & Plates Manufacturers in Mumbai, Hastelloy C276 Sheets & Plates Suppliers in Mumbai, Hastelloy C276 Sheets & Plates Stockists in Mumbai, Hastelloy C276 Sheets & Plates Exporters in Mumbai

Hastelloy C276 Plate they are the most commonly used nickel alloy, like lots of other nickel alloys, it is pliable, easily developed, and also welded. Alloy C276 Plate shows superb deterioration resistance in a range of extreme settings and also media. ASME SB 575 UNS N10276 material displays resistance to deterioration by saltwater in crevice conditions where can generate hostile attack in other commonly utilized materials.

ASTM B575 UNS N10276 Hastelloy C276 Sheet utilized in several industries, consisting of petrochemical, power generation, pharmaceutical, pulp and paper manufacturing and drainage treatment, chemical oil, and gas. The only difference between the Alloy C276 sheet as well as plate steel is the gauge of the metal. Hastelloy Alloy C276 Plate is words utilized to explain the category of metal depending upon its thickness. While sheet steel is less than 3 mm thick, plate steel is certainly thicker than 3 mm.

All Chhajed products are manufactured under strict process control and monitored throughout the production process. They go through several checks to ensure that the product delivered is of finest quality!

Specification Schedule of Hastelloy C276 Sheets & Plates

Product Type Hastelloy C276 ASTM B575 Sheet, Hastelloy C276 ASTM B575 Plate
Specification ASTM B575 / ASME SB575
Tolerances (width / thickness)
  • EN 10258/ DIN 59381)
  • EN 10151 2.4819 Hastelloy C-276 Strips
  • EN 10088 Hastelloy C276 SB575 strips
Dimensions
  • Cold rolled Alloy C276 Plates 0.5-6.4 mm
  • Hot rolled Alloy C276 Plates 3.0–10.0 mm
Thickness 0.1 to 100 mm Thk
Width 10-2500mm
Length 2m, 2.44m, 3m, or as required
Finish SATIN, 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), No.1 finish hot rolled, 1D, No.4, BA, 8K, hairline, brush, mirror etc.
Hardness Soft, Hard, Half Hard, Quarter Hard, Spring Hard
variety of shapes Coils, Foils, Plates, Sheet, Strip, Plain Sheet, Checker Plates, Rolling Sheet, Flats, Clad Plates, Flat Sheet, Shim Sheet, Rolls, Blank (Circle), Rolling Plates, Flat Shim, soft annealed, descaled, tread Plates, sheared, annealed
ASTM B575 N10276 Alloy C276 Plates Hs Code 75062000

Chemical Properties of Hastelloy C276 Sheets & Plates

Hastelloy C276 Analysis
Ni Bal
Mo 15 – 17
Cr 14.5 – 16.5
Fe 4 – 7
W 3 – 4.5
Co 2.5 max
Mn 1.0 max
C 0.01 max
v 0.35 max
P 0.04 max
S 0.03 max
Si 0.08 max

Mechanical Properties of Hastelloy C276 Sheets & Plates

Density 8.89 g/cm3
Melting Range 1370 °C (2500 °F)
Tensile Strength Psi – 1,15,000
MPa – 790
Yield Strength (0.2%Offset) Psi – 52,000
MPa – 355
Elongation 40 %

Equivalent Standard of Hastelloy C276 Sheets & Plates

  Europe America Japan Russia Europe Russia
STANDARD WERKSTOFF NR. UNS JIS GOST EN OR
Alloy C276 2.4819 N10276 NW 0276 ХН65МВУ NiMo16Cr15W ЭП760

Basic Type of Hastelloy C276 Sheets & Plates

Hastelloy C276 Sheets & Plates

Hastelloy C276 Sheets

Hastelloy C276 Sheets & Plates

AISI Hastelloy C276 Plates

Hastelloy C276 Sheets & Plates

ANSI Hastelloy C276 Sheets

Hastelloy C276 Sheets & Plates

Hastelloy C276 Strips

Hastelloy C276 Sheets & Plates

Hastelloy C276 Coil

Hastelloy C276 Sheets & Plates

Pure Hastelloy C276 Plates
