Q195 Low Carbon Steel Pipes
Q195 Low Carbon Steel Pipes Manufacturers in Mumbai, Q195 Low Carbon Steel Pipes Suppliers in Mumbai, Q195 Low Carbon Steel Pipes Stockists in Mumbai, Q195 Low Carbon Steel Pipes Exporters in Mumbai
Q195 brand is a Chinese brand grade of carbon introductory steel ,"q" represents yield quality,"195"signifies the yield quality is 195 Mpa, and inflexibility is 315 – 430 Mpa, information is tried dependent on a 16 mm range brand bar. Q195 material has multiple uses, as the manufacture of line rods, brand plates. It has high flexibility , toughness and weldability, good pressure and processable, but low strength. Wire rods can be cold drawn into low carbon brand lines, either to make black or galvanized iron line, tie line, welded line mesh, line hedge, and multiplex fresh. Cold and hot- rolled steel sheet are universally used in roofing panels, embellishing panels, packaging receptacles, iron cans, instrument cases, switch boxes, preservative covers etc.
Q235 steel is successive to Japanese brand grade SS400 in play, the only difference is that SS400 steel requires only S, P composition < 0.050, Q235, which is fair the same to SS400 245Mpa. The undermining product on Q235 carbon steel is generally brown loose substance, while that on 304 spotless brand is generally light color strain-like one. The undermining extent and the penetration of the carbon blade is big deeper than those for antiseptic blade.
All Chhajed products are manufactured under strict process control and monitored throughout the production process. They go through several checks to ensure that the product delivered is of finest quality!
Specification Schedule of Q195 Low Carbon Steel Pipes
| Production Range |
- SSAW
OD: 219mm - 3120mm
WT: 3mm - 25mm
- LSAW
OD: 16"-64"
WT: max 50mm
- ERW
OD: 1/8"-24"
WT: max 26.5mm
- SMLS
OD: 1/8"-36"
WT: 1.25mm - 50mm
|
| Codes and Standards |
ANSI, ASME, ASTM, API, SAE, BS, AGA, AWWA, ISO, DIN |
| Dimensions |
ASME/ ANSI B36.10 / 19 |
| Pipe schedules |
SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS |
| Producing techniques |
Seamless / ERW / Welded / Fabricated / CDW / EFW |
| Available Shapes |
Round, Half Round, Square, Rectangular or Custom shape |
| Length |
3 to Max18 Meters or custom |
| End |
Beveled End, Plain End, Treaded |
| Test Certificate |
EN 10204 3.1 B |
| Length |
Random Length / Fixed Length / SRL / DRL |
| Usage |
Mechanical Tubing Liquid Transport Steel Pipe
General structure, mechanical structure Transport liquid, gas, oil |
| Test |
- Chemical Component Analysis
- Mechanical Properties (Ultimate tensile strength, Yield strength, Elongation)
- Technical Properties (Flattening Test, Blow Test, Impact Test, Flaring Test, Bending Test, Hardness Test etc)
- Exterior Size Inspection
- Nondestructive Test (Ultrasonic flaw detector, Eddy current flaw detector)
- Hydrostatic Test
|
| Surface |
Fusion bond Expoxy Coating / Coal Tar Expoxy / 3PE / Varnish Coating
Bitumen Coating / Black Oil Coating as per customer's requirement |
| Mill Test Certificate |
EN 10204/3.1B |
Chemical Composition of Q195 Low Carbon Steel Pipes
| Grade |
Chemical Composition |
| C |
Mn |
Si |
S |
P |
| Q195 |
0.06-0.12 |
0.25-0.50 |
≤0.30 |
≤0.045 |
≤0.05 |
| Q215 |
0.09-0.15 |
0.25-0.55 |
≤0.30 |
≤0.05 |
≤0.045 |
| Q235 |
0.12-0.20 |
0.30-0.67 |
≤0.30 |
≤0.045 |
≤0.04 |
| Q345 |
≤0.20 |
1.00-1.60 |
≤0.55 |
≤0.04 |
≤0.04 |
Mechanical Composition of Q195 Low Carbon Steel Pipes
| Grade |
Yield Strength |
Tensile Strength |
| Q195 |
195 |
315-430 |
| Q215 |
215 |
335-450 |
| Q235 |
235 |
370-500 |
| Q275 |
275 |
410-540 |
Basic Type of Q195 Low Carbon Steel Pipes
Q195 Low Carbon Steel ERW Pipes
Q195 Low Carbon Steel Seamless Pipes
Q195 Low Carbon Steel Welded Pipes
Low Q195 Low Carbon Steel Pipes
Q195 Low Carbon Steel Pipes
Cold Rolled Q195 Low Carbon Steel Pipes
