ASTM A519 Gr 4130 Carbon Steel0 Pipes
ASTM A519 Gr 4130 Carbon Steel Pipes Manufacturers in Mumbai, ASTM A519 Gr 4130 Carbon Steel Pipes Suppliers in Mumbai, ASTM A519 Gr 4130 Carbon Steel Pipes Stockists in Mumbai, ASTM A519 Gr 4130 Carbon Steel Pipes Exporters in Mumbai
Steel Rectangular Tubing grade 4130 ASTM A519 contains elements like chromium and molybdenum added in its alloy as strengthening agents. As the lower carbon content is a, welded easy for ASTM A519 4130 Steel Chromoly Tubing. A519 grade 4130 Seamless Steel Tubing material during machining tends to become hard during the time of the hardness of the steel grade has been increased. Machining with the use of conventional methods can be easily done for material Chrome Moly Steel ASTM A519 4130 Boiler Tubing. Alloy ASTM A519 Grade 4130 is produced from steel tube by welding which is been performed by all commercial techniques. Steel ASTM A519 Grade 4130 formation can be done in an annealed condition.
Subsequently cold finished after hot-working the product can be done on A519 gr 4130 Seamless Tubing. ASTM A519 Tubing could be furnished in the shapes like rectangular, round, square as well as special sections. Alloy Steel ASTM A519 4130 Square Tubing could be performed at a temperature which ranges between 816 °C to about 1093°C in hot working. In order to produce the desired shape, dimensions and achieve the resultant properties ASTM A519 Steel perform processes.
All Chhajed products are manufactured under strict process control and monitored throughout the production process. They go through several checks to ensure that the product delivered is of finest quality!
Specification Schedule of ASTM A519 Gr 4130 Carbon Steel0 Pipes
Standard
|
ASTM A519 / ASME SA 519 |
| ASTM A519 |
Standard Specification covers both seamless hot-finished mechanical tubing and seamless cold-finished mechanical tubing |
| Size |
2"- 12" |
| Outer Diameter |
21 to 426 mm |
| Wall Thickness |
2 to 50 mm |
| Schedule |
SCH 20, 30, 40, Standard (STD), 80, 100, 120, 140, 160, XXH, Extra Heavy (XH) |
| Shape |
round, square, rectangular and special sections.
|
| Length |
Not more than 12 m |
| Sizing Methods |
- HF-Hot Finished,
- CW-Cold worked,
- RT-Rough Turned,
- G– Ground.
|
| ASTM A519 treatment conditions |
- A-Anealed,
- N– Normalized,
- QT-Quenched and Tempered,
- SR-Stress Relieved or Finishe Anneal.
|
Chemical Composition of ASTM A519 Gr 4130 Carbon Steel0 Pipes
| Grade |
C |
Mn |
P≤ |
S≤ |
Si |
Cr |
Mo |
| 4130 |
0.28-0.33 |
0.40-0.60 |
0.040 |
0.040 |
0.15-0.35 |
0.80-1.10 |
0.15-0.25 |
Mechanical Composition of ASTM A519 Gr 4130 Carbon Steel0 Pipes
| Condition |
Ultimate Strength |
Yield Strength |
Elongation in 2 in.or 50mm,% |
Rockwell, Hardness B Scale |
| ksi |
Mpa |
ksi |
Mpa |
| Hot Rolled (HR) |
90 |
621 |
70 |
483 |
20 |
89 |
| Stress Relieved (SR) |
105 |
724 |
85 |
586 |
10 |
95 |
| Annealed (A) |
75 |
517 |
55 |
379 |
30 |
81 |
| Normalized (N) |
90 |
621 |
60 |
414 |
20 |
89 |
Equivalent Grade of ASTM A519 Gr 4130 Carbon Steel0 Pipes
| Grade |
ASTM A519 AISI 4130 |
| UNS |
G41300 |
| DIN |
1.7218 |
| EN |
25CrMo4 |
| JIS |
JIS G4105 |
| BS |
BS 970 |
Basic Type of ASTM A519 Gr 4130 Carbon Steel0 Pipes
ASTM A519 Gr 4130 Carbon Steel0 Pipes
ASTM A519 Gr 4130 Carbon Steel0 Pipes
ASTM A519 Gr 4130 Carbon Steel0 Pipes
Low ASTM A519 Gr 4130 Carbon Steel0 Pipes
ASTM A519 Gr 4130 Carbon Steel0 Pipes
Cold Rolled ASTM A519 Gr 4130 Carbon Steel0 Pipe
