ASTM A519 Gr 4140 Carbon Steel Pipes
ASTM A519 Gr 4140 Carbon Steel Pipes Manufacturers in Mumbai, ASTM A519 Gr 4140 Carbon Steel Pipes Suppliers in Mumbai, ASTM A519 Gr 4140 Carbon Steel Pipes Stockists in Mumbai, ASTM A519 Gr 4140 Carbon Steel Pipes Exporters in Mumbai
A519 grade 4140 Seamless Steel Tubing is a combination steel grade which contains alloy like molybdenum, chromium and manganese. The ASTM A519 grade 4140 is low composite steel, which offers superior qualities. For example, few of the vital characteristics of determined A519 4140 Chrome Alloy Steel Hf seamless steel pipe Tubing consist of high exhaustion strength, high abrasion and effect obstruction, alongside great durability, and torsional strength properties. As commonplace of this alloy steel, this specific determined Alloy Steel A519 4140 Square Tubing material could be welded utilizing all traditional shop practices.
The A519 grade 4140 Seamless Tubing fabricated under this specification is a rounded item made without a welded seam. The cylinders are normally manufactured by hot working of the steel. And also, if required, the A519 Grade 4140 Steel Tubing can be created along with the lines cold completing the hot worked product for example the ASTM A519 tube to accomplish the desired shape, yet in addition the desired measurements and properties. The A519 4140 Hot Finished Tubing material can be outfitted in any of the accompanying shapes for example round, rectangular or square. Hotness examination is consistently directed on the Chrome Moly Steel ASTM A519 4140 Boiler Tubing to decide the predetermined percentages of the components.
All Chhajed products are manufactured under strict process control and monitored throughout the production process. They go through several checks to ensure that the product delivered is of finest quality!
Specification Schedule of ASTM A519 Gr 4140 Carbon Steel Pipes
| Standard
|
ASTM A519 / ASME SA 519 |
| ASTM A519 |
Standard Specification covers both seamless hot-finished mechanical tubing and seamless cold-finished mechanical tubing |
| Size |
2.375" to 12.750". |
| Outer Diameter |
1/4" to 30" |
| Wall Thickness |
0.375" to 1.500". |
| Schedule |
20, 30, 40, 80, 100, 120, 140, 160, XXH, Standard (STD), Extra Heavy (XH) |
| Shape |
Rounded, squared, hex, rectangular and special sections.
|
| Length |
Max 12 m |
| Grade |
4140, L80 and P110 heat treated mechanicals. |
Chemical Composition of ASTM A519 Gr 4140 Carbon Steel Pipes
| C |
Mn |
P≤ |
S≤ |
Si |
Cr |
Mo |
| 0.38-0.43
| 0.75-1.00 |
0.040 |
0.040 |
0.15-0.35 |
0.80-1.10 |
0.15-0.25 |
Mechanical Composition of ASTM A519 Gr 4140 Carbon Steel Pipes
| Condition |
Tensile Strengtd Rm (Mpa) |
Yield Strengtd R2 (Mpa) |
Elongation in 2 in or 50 mm A(%) |
Rockwell, Hardness B Scale |
| HF(Hot Finished) |
855 min (120 ksi) |
621 min (90 ksi) |
15 min |
100 |
| SR(Stress Relieved) |
855 min (120 ksi ) |
689 min (100 ksi) |
10 min |
100 |
| A(Annealed) |
552 min (80 ksi ) |
414 min (60 ksi) |
25 min |
85 |
| N (Normalized) |
855 min (120 ksi ) |
621 min (90 ksi) |
20 min |
100 |
| Q+T (Quenched and tempered.) |
AS your requirements |
|
|
|
Equivalent Grade of ASTM A519 Gr 4140 Carbon Steel Pipes
| Grade |
ASTM A519 AISI 4140 |
| UNS |
G41400 |
| DIN |
1.7225 |
Basic Type of ASTM A519 Gr 4140 Carbon Steel Pipes
ASTM A519 Gr 4140 Carbon Steel Pipes
ASTM A519 Gr 4140 Carbon Steel Pipes
ASTM A519 Gr 4140 Carbon Steel Pipes
Low ASTM A519 Gr 4140 Carbon Steel Pipes
ASTM A519 Gr 4140 Carbon Steel Pipes
Cold Rolled ASTM A519 Gr 4140 Carbon Steel Pipe
