The ASTM A519 Grade 1026 tube is usually manufactured by hot working steel. The hot worked steel manufactured under this specification could either be carbon steel or this process could be used to make the ASTM A519 1026 Chrome Alloy Steel Hf Smls Tubing. The specified ASTM A519 Grade 1026 tubes, are generally furnished in the following shapes i.e. rectangular, round or square. If required, At Chhajed Steel & Alloy Pvt Ltd, we manufacture these ASTM A519 Grade 1026 Mechanical Tubing furnished in special sections, according to the need of our clients or if required by the application for which it is to be used for.
Heat analysis is usually performed on the ASTM A519 Grade 1026 Steel Tubing in order to determine the percentages of the elements specified in the material used to make these tubes. Although If secondary melting processes are used in the melting of A519 gr 1026 Seamless Tubing, the heat analysis could be obtained either from one re-melted ingot or the product of one re-melted ingot of every single primary melt. The ASTM A519 1026 Hot Finished Tubing has to be coated with a film of oil before shaping to retard rust when specified
All Chhajed products are manufactured under strict process control and monitored throughout the production process. They go through several checks to ensure that the product delivered is of finest quality!
Specification Schedule of ASTM A519 Gr 1026 Carbon Steel Pipes
Standard
|
ASTM A519 / ASME SA 519 |
| ASTM A519 |
This standard covers seamless hot-finished and cold-finished mechanical tubing |
| Size Range |
12 3/4(323.8mm) |
| Outer Diameter (OD) |
6.25-1800mm |
| Pipe Schedule |
10 – XXS / Thk |
| Shape |
round, square, rectangular, hex and special shape.
|
| Length |
Single / Double random length
or as customer's actual request |
| Grade |
SAE 1026 / AISI 1026 / GRADE 1026. |
| Mill test certificates |
EN10204.3 |
| Terms of sale |
- All tubes shall be supplied as per applicable ASTM A519 Specification.
- Orders for material under A519 should provide delivery condition (A, N, QT, SR)
|
Chemical Composition of ASTM A519 Gr 1026 Carbon Steel Pipes
| Grade |
C |
Mn |
P≤ |
S≤ |
| 1026 |
0.22-0.28 |
0.60-0.90 |
0.040 |
0.050 |
Mechanical Composition of ASTM A519 Gr 1026 Carbon Steel Pipes
| Properties |
Metric |
Imperial |
| Tensile strength |
490 MPa |
71100 psi |
| Yield strength |
415 MPa |
60200 psi |
| Bulk modulus (typical for steel) |
140 GPa |
20300 ksi |
| Shear modulus (typical for steel) |
80.0 GPa |
11600 ksi |
| Hardness, Brinell |
143 |
143 |
| Hardness, Knoop (converted from Brinell hardness) |
163 |
163 |
| Hardness, Rockwell B (converted from Brinell hardness) |
78 |
78 |
| Hardness, Vickers (converted from Brinell hardness) |
149 |
149 |
| Elastic modulus |
190-210 GPa |
27557-30458 ksi |
| Poisson's ratio |
0.27-0.30 |
0.27-0.30 |
| Elongation at break (In 50 mm) |
15.00% |
15.00% |
| Reduction of area |
40.00% |
40.00% |
Machinability (based on AISI 1212 steel as 100 machinability.
The machinability of Group I bar, rod, and wire products can be improved by cold drawing.) |
75 |
75 |
Basic Type of ASTM A519 Gr 1026 Carbon Steel Pipes
ASTM A519 Gr 1026 Carbon Steel Pipes
ASTM A519 Gr 1026 Carbon Steel Pipes
ASTM A519 Gr 1026 Carbon Steel Pipes
Low ASTM A519 Gr 1026 Carbon Steel Pipes
ASTM A519 Gr 1026 Carbon Steel Pipes
Cold Rolled ASTM A519 Gr 1026 Carbon Steel Pipe
