ASTM A283 Carbon Steel Gr C Sheets & Plates
ASTM A283 Carbon Steel Gr C Manufacturers in Mumbai, ASTM A283 Carbon Steel Gr C Suppliers in Mumbai, ASTM A283 Carbon Steel Gr C Stockists in Mumbai, ASTM A283 Carbon Steel Gr C Exporters in Mumbai
ASTM A283 Grade C used for general purpose structural applications of medium strength (60 KSI tensile) requirement. ASTM A283 Grade C Carbon Steel Plate can be welded by all conventional methods. Its heat treatment consists of normalizing at 1650 F and slow furnace cool. ASTM A283 Grade A structural steel plates it has the lowest strength and highest ductility compared to the other grade of ASTM A283 steel. There is a low & intermediate tensile strength hot Rolled steel for general intermediate strength applications. ASTM A283 Grade B is made by one or more of the following processes such as the electric furnace, open hearth, and basic oxygen. They enhanced shall conform to the requirements of the current specification a6/a6m.
ASTM A283 Grade A structural steel plates have the lowest strength and highest ductility compared to the other grade of ASTM A283 steel and are the lowest strength and highest ductility compared to the other grade of ASTM A283 steel. ASTM A283 Grade D boiler steel is relatively higher in strength than A283 GRC. It is low & intermediate tensile strength hot rolled steel in the form of plates for general intermediate strength applications.
All Chhajed products are manufactured under strict process control and monitored throughout the production process. They go through several checks to ensure that the product delivered is of finest quality!
Specification Schedule of ASTM A283 Carbon Steel Gr C Sheets & Plates
| Specifications |
ASTM A283 / ASME SA283 |
| Standard |
AISI, ASTM, BS, DIN, GB, JIS |
| Thickness |
6MM to 300MM, |
| Specialize |
Shim Sheet, Perforated Sheet, B. Q. Profile. |
| Length |
3000mm to 15000mm |
| Form |
Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) |
| Finish |
Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness |
Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Grade |
MS A283 GR.C, (UNS K02401) |
Chemical Composition of ASTM A283 Carbon Steel Gr C Sheets & Plates
| |
Grade A |
Grade B |
Grade C |
Grade D |
| Carbon, max |
0.14 |
0.17 |
0.24 |
0.27 |
| Manganese, max |
0.90 |
0.90 |
0.90 |
0.90 |
| Phosphorus, max |
0.035 |
0.035 |
0.035 |
0.035 |
| Sulphur, max |
0.04 |
0.04 |
0.04 |
0.04 |
| Silicon |
0.40 0.15-0.40 |
0.40 0.15-0.40 |
0.40 0.15-0.40 |
0.40 0.15-0.40 |
| Copper min % when copper steel is specified |
0.20 |
0.20 |
0.20 |
0.20 |
Mechanical Composition of ASTM A283 Carbon Steel Gr C Sheets & Plates
| |
Grade A |
Grade B |
Grade C |
Grade D |
| Tensile Strength: |
45,000 -60,000 psi
[310 - 415 MPa]
|
50,000 -65,000 psi
[345 - 450 MPa]
|
55,000 75,000 psi
[380 - 515 MPa]
|
60,000 -80,000 psi
[415 - 550 MPa]
|
| Min. Yield Point: |
24,000psi
[165 MPa]
|
27,000psi
[185 MPa]
|
30,000psi
[205 MPa]
|
33,000psi [
230 MPa]
|
| Elongation in 8": |
27% min |
25% min |
22% min |
20% min |
| Elongation in 2": |
38% min |
28% min |
25% min |
23% min |
Equivalent Material Grade of ASTM A283 Carbon Steel Gr C Sheets & Plates
| STANDARD |
WERKSTOFF NR. |
UNS |
| MS A283 GR.C |
1.0036 |
K02401 |
Basic Type of ASTM A283 Carbon Steel Gr C Sheets & Plates
ASTM A283 Carbon Steel Gr C Sheets & Plates
ASTM A283 Carbon Steel Gr C Sheets & Plates
ASTM A283 Carbon Steel Gr C Plates
Low ASTM A283 Carbon Steel Gr C Sheets
ASTM A283 Carbon Steel Gr C Sheets & Plates
Cold Rolled ASTM A283 Carbon Steel Gr C Sheets
16mm Thk Ms ASTM A283 Carbon Steel Gr Cs Plate
Hot Rolled ASTM A283 Carbon Steel Gr C Sheets
Mild ASTM A283 Carbon Steel Gr C Plate
