Alloy 31 Pipes

Alloy 31 Pipes, Alloy 31 Pipes Manufacturers, Alloy 31 Pipes Suppliers, Alloy 31 Pipes Stockists, Alloy 31 Pipes Exporters

Alloy 31 Pipes Manufacturers In India, Alloy 31 Pipes Suppliers In India, Alloy 31 Pipes Stockists In India, Alloy 31 Pipes Exporters In India

Alloy 31 Pipes

Stainless Steel Pipes

Alloy 31 Pipes Manufacturers in Mumbai, Alloy 31 Pipes Suppliers in Mumbai, Alloy 31 Pipes Stockists in Mumbai, Alloy 31 Pipes Exporters in Mumbai

Alloy 31 N08031 Electropolished Pipes has strong resistance to both corrosion and erosion corrosion, especially in phosphoric acid containing environments. The Nicrofer 3127 hMo UNS S08031 Pipe demonstrates excellent resistance to corrosion in not only sulfuric acid, but also in reducing and oxidizing media. ASTM B626 UNS S08031 Polished Pipes are used in applications such as pulp and paper industry, sea water heat exchangers, flue gas desulphurization - FGD - systems, petroleum production and refining industry as well as in mining industry, ore processing etc.

Typically alloy grade uns n08031 seamless pipe is known to have a PREN value of ≥ 48. A higher PREN value or pitting resistance equivalent number indicates that the resistance to pitting corrosion of that particular alloy grade is high. The alloy 31 seamless pipe can be used in settings where the temperature ranges between -196°C to 550°C. Additionally, since the alloy 31 welded pipe has very good weldability properties, it can be used for welding based applications as well.

Alloy 31 Pipes are very superior to alloy 625 pipe & other nickel alloy pipe and suitable for transporting extremely corrosive liquids. When the Alloy 31 pipe used in the presence of boiling 67% nitric acid, the alloy has Excellent resistance to both general and localized corrosion as well. It is used in Chloridoxid bleaching plants in paper production. Alloy 1.4562 welded pipes also has the ability to resist corrosion even in alkaline and acid halide containing media.

All Chhajed products are manufactured under strict process control and monitored throughout the production process. They go through several checks to ensure that the product delivered is of finest quality!

Specification Schedule of Alloy 31 Pipes

Specifications ASTM A/ASME SA213/ A249/ A269/ A312/ A358 CL. I to V, PED 97/23/EC, EN 10216-5 TC1 / TC2, AD 2000, NACE MR0175/ ISO 15156
Standard Size 1/8"NB TO 30" NB IN
Alloy 31 Seamless Pipes 1/2" NB - 16" NB
SS Alloy 31 ERW Pipe 1/2" NB - 24" NB
SS Alloy 31 EFW Pipe 6" NB - 100" NB
Outer Diameter 6.00 mm OD up to 914.4 mm OD, Sizes up to 24" NB
Thickness 0.3 - 50 mm, SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS, LSAW, SSAW, HSAW
Manufacturing techniques Seamless / ERW / Welded / Fabricated / CDW / EFW
Shape Round, Half Round, Square, Rectangular or Custom
Length Single Random, Double Random & Custom Length
Pipe End Plain End, Beveled End, Treaded
Test Certificate EN 10204 3.1 B

Alloy 31 round pipes

Size range

Wall thickness: 1mm- 150mm (SCH10-XXS)

Outer diameter: 6mm- 2500mm (3/8"-100")

Nickel Alloy N08031 square pipe

Size range

Wall thickness: 1mm- 150mm (SCH10-XXS)

Outer diameter: 4mm*4mm- 800mm*800mm

Alloy 31 UNS N08031 rectangular pipes

Size range

Wall thickness: 1mm-150mm (SCH10-XXS)

Outer diameter: 6mm-2500mm (3/8"-100")

Length: 4000mm, 5800mm, 6000mm, 12000mm, or as required.

Chemical Properties of Alloy 31 Pipes

C - 0.0015
Si - 0.3
Mn - 2
P - 0.02
S - 0.01
Cr 26 28
Cu 1 1.4
Fe Balance
Mo 6 7
N 0.15 0.25
Ni 30 32

Mechanical Properties of Alloy 31 Pipes

Temper Annealed
Tensile Rm 94 ksi (min)
Tensile Rm 650 MPa (min)
R.p. 0.2% Yield 41 ksi (min)
R.p. 0.2% Yield 280 MPa (min)
Elongation (2.02 or 4D gl) 40 % (min)

Physical Properties of Alloy 31 Pipes

Specific Heat (0-100°C) 452 J.kg-1.°K-1
Thermal Conductivity 11.7 W.m -1.°K-1
Thermal Expansion 18.1 mm/m/°C
Modulus Elasticity 198 GPa
Electrical Resistivity 1.03 μohm/cm
Density 8.61 g/cm3
