Stainless Steel 410 Pipes, Stainless Steel 410 Pipes Manufacturers, Stainless Steel 410 Pipes Suppliers, Stainless Steel 410 Pipes Stockists, Stainless Steel 410 Pipes Exporters
Stainless Steel 410 Pipes Manufacturers In India, Stainless Steel 410 Pipes Suppliers In India, Stainless Steel 410 Pipes Stockists In India, Stainless Steel 410 Pipes Exporters In India
Stainless Steel 304 Pipes
Stainless Steel 410 Pipes Manufacturers in Mumbai, Stainless Steel 410 Pipes Suppliers in Mumbai, Stainless Steel 410 Pipes Stockists in Mumbai, Stainless Steel 410 Pipes Exporters in Mumbai
410 pipe material has good corrosion resistance along with high strength and hardness and is used for the application which involves heat resistance, mild corrosion and high strength. It is a general purpose martensitic stainless steel which contains 11.5% chromium and this provide properties of good corrosion resistance. It obtains maximum heat and corrosion resistance through hardening. However the corrosion resistance can be further enhanced by the process of hardening, tempering and polishing. Tempering and quenching can harden alloy 410. 410 Seamless Pipes process annealing can be carried at temperatures ranging from 650 to 760 °C and air-cooled. It can be fully annealed at temperature ranging between 815 – 900 °C, followed by air cooling and slow furnace.
SA 312 tp 410 at temperatures up to 650 °C Grade 410 has good scaling resistance. It is resistant to steam, hot gases, mild acids and alkalies, food, air and fresh water. However it tends to reduce its mechanical properties at temperature ranging from 400 – 580 °C. Stainless Steel 410 Pipe is welded by using all conventional welding techniques but it should be pre heated at 150 – 260 °C followed by post weld annealing treatment to mitigate cracking. SS 410 welding rods are recommended for tempering and post-hardening. ASTM A312 tp 410 its heavy sections need to be oil quenched. Tempering process is been done to enhance the mechanical properties and hardness. It can be hardened at temperature ranging between 925 – 1010 °C, followed by oil or air quenching.
All Chhajed products are manufactured under strict process control and monitored throughout the production process. They go through several checks to ensure that the product delivered is of finest quality!
Specification Schedule of Stainless Steel 410 Pipes
| SS 410 Specification |
Stainless Steel 410, WERKSTOFF NR. 1.4006 SS 410 |
| 410 SS Pipe |
Stainless Steel 410 Pipe |
| DIN 1.4006 SS 410 Seamless Pipe Size |
4 to 219mm W. T.: 0.5 to 20mm |
| TP410 A312 Welded Pipe Size |
5.0 mm – 1219.2 mm |
| A269 Stainless Steel EFW Pipe size |
5.0 mm – 1219.2 mm |
| Stainless Steel UNS S41000 Pipe Swg & Bwg |
10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| UNS S41000 Pipe Schedule |
SCH5, SCH10, SCH10S, SCH20, SCH30, SCH40, SCH40S, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| 410 SS Swg & Bwg |
10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| Stainless Steel 410 Tube wall thickness |
0.020" –0.220", (special wall thicknesses available) |
| ASTM A 312 SS 410 Length |
Single Random, Double Random, Standard & Cut length Pipe & Tube |
| 410 Steel Finish |
Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF |
| ASTM A 358 SS 410 Form |
Round, Hydraulic, 'U' bent or Hollow,LSAW, Boiler, Straight Pipe, Clad Pipe, Rectangular, Square Pipe Etc |
| Stainless Steel 410 Type |
Welded, Seamless, ERW, EFW, Fabricated Pipe, 'U' bent or Hollow, Hydraulic, LSAW, Boiler, Straight Tube, Tube Coil, Round, Rectangular, Square Tube etc |
| ASTM A 312 SS 410 End |
Plain End, Beveled End, Treaded Pipe |
| DIN 1.4006 SS 410 Marking |
All Stainless Steel 410 Pipe are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer's request.) |
| WERKSTOFF NR. 1.4006 SS 410 Value Added Service |
Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc. |
| SS TP410 Specialize in |
- ASTM A312 TP 410 SS Large Diameter Pipe
- SS 410 Capillary Tube
- Alloy 410 Heat Exchanger &
- WERKSTOFF NR.1.4449 SS 410 Condenser Tube
|
| Alloy 410 Test Certificate |
Manufacturer Test Certificate
Laboratory Test Certificate from Govt. Approved Lab.
Under Third Party Inspection |
| We can also cut, thread, and groove Stainless Steel 410 Pipe to meet your specifications. Pipe Dimension ANSI/ ASME B36.10, B36.19, B2.1 |
Chemical Properties of Stainless Steel 410 Pipes
| Grade |
C |
Mn |
Si |
P |
S |
Cr |
Mo |
Ni |
N |
| 410 |
min. |
– |
– |
– |
– |
– |
11.5 |
– |
– |
– |
| max. |
0.15 |
1.0 |
1.00 |
0.040 |
0.030 |
13.5 |
– |
0.75 |
– |
Mechanical Properties of Stainless Steel 410 Pipes
| Grade |
Tensile Strength (MPa) min |
Yield Strength 0.2% Proof (MPa) min |
Elongation (% in 50mm) min |
Hardness |
| Rockwell B (HR B) max |
Brinell (HB) max |
| 410 |
480 |
275 |
16 |
95 |
201 |
Equivalent Standard of Stainless Steel 410 Pipes
| Grade |
UNS No |
Old British |
Euronorm |
Swedish SS |
Japanese JIS |
| BS |
En |
No |
Name |
| 410 |
S41000 |
410S21 |
56A |
1.4006 |
X12Cr13 |
2302 |
SUS 410 |
Basic Type of Stainless Steel Pipes
Stainless Steel 410 Seamless Pipe
Stainless Steel 410 Welded Pipe
3 Inch Stainless Steel 410 Pipe
Jindal Stainless Steel 410 Pipe
Stainless Steel 410 Exhaust Pipe
Stainless Steel 410 Flex Pipe
Stainless Steel 410 Square Pipe
Polished Decorative Schedule 10 Stainless Steel 410 Pipe
8 Inch Seamless Stainless Steel 410 Pipe
Thickness 9.0mm aisi Stainless Steel 410 seamless pipe
Food Grade Stainless Steel 410 Welded Square Pipe
