Stainless Steel 347/347H Pipes
Stainless Steel 347/347H Pipes Manufacturers in Mumbai, Stainless Steel 347/347H Pipes Suppliers in Mumbai, Stainless Steel 347/347H Pipes Stockists in Mumbai, Stainless Steel 347/347H Pipes Exporters in Mumbai
Stainless Steel 347 is a general purpose austenitic stainless steel with a face centered cubic structure. Its pipe is an iron based alloy containing at least chromium 10%. It is non-magnetic in the annealed condition and can harden only by cold working. In order to suppress the grain boundary Chromium Carbide precipitation niobium is been added. Through the formation of an invisible and adherent chromium rich oxide film it achieves its stainless steel characteristics.
Stainless Steel 347 seamless pipe is advantageous for high temperature service because of its good mechanical properties. It has moderately improved corrosion resistance over stainless steel 321 in strongly oxidizing environment. Astm a312 tp 347h is quite tough and ductile so it can be readily stamped, blanked, spun and drawn. SA312 tp347h is unresponsive to heat treatment so the hardness and strength can be increased through cold working. The stainless steel at temperature range of 1010 - 1193°C can be annealed and then quenched with water.
347h seamless pipe is slightly tougher than that of 304 stainless steel. However, by the use of constant positive feeds and slow speeds hardenability can be minimized. ASTM A312 TP 347 is developed to provide an 18-8 type alloy with improved intergranular-corrosion resistance. It is a columbium/tantalum stabilized austenitic chromium-nickel stainless steel.
In strongly oxidizing environments SA 312 Tp 347 has a slightly improved corrosion resistance over other stainless steel alloys as a result of the addition of columbium (niobium) and tantalum. Stainless Steel 347H Pipe is high-alloy steels it has high corrosion resistance than other steels owing to the presence of large amounts of chromium in the range of 4 - 30%.
All Chhajed products are manufactured under strict process control and monitored throughout the production process. They go through several checks to ensure that the product delivered is of finest quality!
Specification Schedule of Stainless Steel 347/347H Pipes
| SS TP347 Standards |
347 Stainless Steel |
| ASTM A249 TP 347 Stainless Steel Seamless Tube Size |
3.35 mm OD To 101.6 mm OD |
| SS 347 Welded Tube Size |
6.35 mm OD To 152 mm OD |
| SS TP347H Swg & Bwg |
10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| ASME SA213TP 347H Stainless Steel Tube Wall Thickness |
0.020" –0.220", (special wall thicknesses available) |
| TP347 SS Length |
Single Random, Double Random, Standard & Cut length Tube |
| Stainless Steel WERKSTOFF NR. 1.4961 Finish |
Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF |
| ASTM A269 TP 347H Stainless Steel Form |
'U' bent or Hollow, Hydraulic, LSAW, Boiler, Straight Tube, Tube Coil, Round, Rectangular, Square Etc |
| SS TP347H Type |
Seamless, ERW, EFW, Welded, Fabricated Tube |
| ASTM A249 TP 347 Stainless Steel End |
Plain End, Beveled End, Treaded Tube |
| ASTM A213 Gr. TP347 Marking |
All 347 Stainless Steel Tube are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer's request.) |
| SS UNS S34709 Application |
Oil Tube, Gas Tube, Fluid Tube, Boiler Tube, Heat exchanger Tube, |
| Stainless Steel 347H Value Added Service |
Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc. |
| 347 Stainless Steel Specialize in |
GOST 08Ch18N12B Capillary Tube & Other Odd Size
SS TP347 Heat Exchanger & Condenser Tube |
| ASTM A213 Gr. TP347 Test Certificate |
Manufacturer Test Certificate
Laboratory Test Certificate from Govt. Approved Lab.
Under Third Party Inspection |
| SS 347 Manufacturers of 347 Stainless Steel Tubes & Tubing |
- Kobe Special Tube, Japan
- Sumitomo Metals, Japan
- Nippon Steel Corporation, Japan
- Sanyo Special Steel, Japan
- Tubacex Tubos Inoxidables S.A., Spain
- Schoeller Bleckmann, Austria
- Seah Steel Corporation, Korea
|
| We can also cut, thread, and groove 347 Stainless Steel Tube to meet your specifications. Tube Dimension ANSI/ ASME B36.10, B36.19, B2.1 |
Chemical Properties of Stainless Steel 347/347H Pipes
SS 347H |
|
| Ni |
9 – 13 |
| Cr |
17 – 19 |
| C |
0.04 – 0.10 |
| Mo |
3 – 4 |
| Fe |
Balance |
| Mn |
2 max |
| Si |
0.75 max |
| S |
0.03 max |
| P |
0.045 max |
| Co + Ta |
8xC min
1.00 max |
Mechanical Properties of Stainless Steel 347/347H Pipes
| Density |
8.0 g/cm3 |
| Melting Point |
1454 °C (2650 °F) |
| Tensile Strength |
Psi – 75000 , MPa – 515 |
| Yield Strength (0.2%Offset) |
Psi – 30000 , MPa – 205 |
| Elongation |
35 % |
Equivalent Standard of Stainless Steel 347/347H Pipes
| Stainless Steel SS 347H |
| AISI |
347 |
347H |
| UNS |
S34700 |
S34709 |
| Werkstoff Nr. |
1.4550 |
1.4961 |
Basic Type of Stainless Steel Pipes
Stainless Steel 347/347H Pipe
Stainless Steel 347/347H Seamless Pipe
Stainless Steel 347/347H Welded Pipe
3 Inch Stainless Steel 347/347H Pipe
Jindal Stainless Steel 347/347H Pipe
Stainless Steel 347/347H Exhaust Pipe
Stainless Steel 347/347H Flex Pipe
Stainless Steel 347/347H Square Pipe
Polished Decorative Schedule 10 Stainless Steel 347/347H Pipe
8 Inch Seamless Stainless Steel 347/347H Pipe
Thickness 9.0mm aisi Stainless Steel 347/347H seamless pipe
Food Grade Stainless Steel 347/347H Welded Square Pipe
