Stainless Steel WP317L Pipe Fittings, Stainless Steel WP317L Pipe Fittings Manufacturers, Stainless Steel WP317L Pipe Fittings Suppliers, Stainless Steel WP317L Pipe Fittings Stockists, Stainless Steel WP317L Pipe Fittings Exporters
Stainless Steel WP317L Pipe Fittings Manufacturers In India, Stainless Steel WP317L Pipe Fittings Suppliers In India, Stainless Steel WP317L Pipe Fittings Stockists In India, Stainless Steel WP317L Pipe Fittings Exporters In India
Stainless Steel WP317L Pipe Fittings
Stainless Steel WP317L Pipe Fittings Manufacturers in Mumbai, Stainless Steel WP317L Pipe Fittings Suppliers in Mumbai, Stainless Steel WP317L Pipe Fittings Stockists in Mumbai, Stainless Steel WP317L Pipe Fittings Exporters in Mumbai
317L Fittings contains molybdenum it is a low carbon austenitic stainless steel fitting with additions of nickel, chromium, and molybdenum for better corrosion resistance and increased resistance to chemical attack for formic, sulfurous, acetic, citric, and tartaric acids. Stainless Steel 317L Pipe Fittings are useful in applications such as paper and pulp handling equipment, chemical and petrochemical processing equipment, power generation stations, Food processing equipment, textile equipment, etc. It has superior corrosion resistance in difficult environments including a wide range of chemicals, especially in acidic chloride environments. 317L elbow provides a change direction in material flow.
This adds pressure losses to the system due to its friction, re-acceleration and impact. The product is then diverted at an angle towards the outlet of the elbow. As the product enters the elbow inlet, it continues moving ahead to the primary impact zone. The turning angle is determined by the elbow design, conveying velocity, product characteristic and specific load. A403 WP317L Tee is a short piece of pipe with 90° branch at the centre. They are used for collecting or distributing the fluid from the run pipe. There are two types of tee used in piping system, i.e. equal tee and unequal tee.
All Chhajed products are manufactured under strict process control and monitored throughout the production process. They go through several checks to ensure that the product delivered is of finest quality!
Specification Schedule of Stainless Steel WP317L Pipe Fittings
| Specifications |
ASTM A403 / ASME SA403 |
| Size |
1/8 inch NB TO 48 inch NB. (Seamless & 100% X-Ray Welded, Fabricated) |
Standards
|
ASME/ANSI B16.9, ASME B16.28, MSS-SP-43 |
| Thickness |
5s, 10s, 40s, 80s, 10, 20, 40, STD, 60, 80, XS, 100, 120, 140, 160, XXS Supplier |
| Type |
Seamless, Welded, Fabricated |
Chemical Properties of Stainless Steel WP317L Pipe Fittings
| Grade |
C |
Mn |
Si |
P |
S |
Cr |
Mo |
Ni |
Fe |
| 317 |
0.08 max |
2.0 max |
1.0 max |
0.045 max |
0.030 max |
18.00 - 20.00 |
3.00 - 4.00 |
11.00 - 15.00 |
57.845 min |
| 317L |
0.035 max |
2.0 max |
1.0 max |
0.045 max |
0.030 max |
18.00 - 20.00 |
3.00 - 4.00 |
11.00 - 15.00 |
57.89 min |
Mechanical Properties of Stainless Steel WP317L Pipe Fittings
| Density |
Melting Point |
Tensile Strength |
Yield Strength (0.2%Offset) |
Elongation |
| 7.9 g/cm3 |
1400 °C (2550 °F) |
Psi – 75000 , MPa – 515 |
Psi – 30000 , MPa – 205 |
35 % |
Equivalent Standard of Stainless Steel WP317L Pipe Fittings
| STANDARD |
WERKSTOFF NR. |
UNS |
JIS |
EN |
| 317 |
1.4449 |
S31700 |
SUS 317 |
- |
| 317L |
1.4438 |
S31703 |
SUS 317L |
X2CrNiMo18-15-4 |
Basic Type of Stainless Steel Pipe Fittings
ASTM A403 WP317L SS Pipe Fittings
ANSI WP317L SS Socket Weld Fittings
UNS S32100 SS WP317L Pipe Fittings
WP317L SS WNR 1.4541 Pipe Fittings
ASME SA 403 SS WP317L Pipe End Cap
WP317L SS Weld Pipe Fittings
SS WP317L 45 Degree Elbow Pipe Fittings
WP317L SS Pipe Coupling 150LB Fittings
WP317L SS 90 Degree Elbow Pipe Fittings
1/4 INCH NPT THREAD WP317L SS Male Adapter Fittings
