EN 10216-5 Stainless Steel Pipes

EN 10216-5 Stainless Steel Pipes, EN 10216-5 Stainless Steel Pipes Manufacturers, EN 10216-5 Stainless Steel Pipes Suppliers, EN 10216-5 Stainless Steel Pipes Stockists, EN 10216-5 Stainless Steel Pipes Exporters

EN 10216-5 Stainless Steel Pipes Manufacturers In India, EN 10216-5 Stainless Steel Pipes Suppliers In India, EN 10216-5 Stainless Steel Pipes Stockists In India, EN 10216-5 Stainless Steel Pipes Exporters In India

1.0576 material and S355J2H Square Tube supplier in India

EN 10216-5 Stainless Steel Pipes Manufacturers in Mumbai, EN 10216-5 Stainless Steel Pipes Suppliers in Mumbai, EN 10216-5 Stainless Steel Pipes Stockists in Mumbai, EN 10216-5 Stainless Steel Pipes Exporters in Mumbai

EN 10216-5 Stainless Steel Seamless Tubes is considered for pressure purposes. This feature of the stainless steel seamless tube is important because this type of tube is constantly put to use where extreme conditions prevail and where safety of people and the trouble-free operation of plant and equipment must be ensured. It is made to resist the greatest heat and the highest pressure and it is unaffected by acids and is corrosion resistant. It provides high strength-to-weight ratio and can be processed to provide a combination of good surface quality, dimensional accuracy, good machinability, excellent micro-structure uniformity and high tensile properties. It well suited for such post-treatments as carburizing and heat treating.

All Chhajed products are manufactured under strict process control and monitored throughout the production process. They go through several checks to ensure that the product delivered is of finest quality!

Specification Schedule of EN 10216-5 Stainless Steel Pipes

Product	DIN EN 10216-5 seamless, cold drawn and high precision tubes
ASTM	ASTM A269 / A213
EN 10216-5 Hydraulic Tubes Grades	1.4571 (SS/ AISI 316Ti) 1.4301 (SS/ AISI 304) 1.4404 (SS/ AISI 316L) 316 / 316L 317L 6Mo 904L Alloy 400 Alloy 625 Alloy 825 Alloy C-276 Duplex Super Duplex Titanium and other special materials
Type	Straight
Finish	CFA (bright annealed)
Class	TC1 and TC2
Outside Diameter	6 - 42 mm
Temperature (min)	-70 (and up) °C, -94 and up °F
Temperature (max)	up to 650 °C, up to 1200 °F
EN 10216-5 TC1	1/2" up to 24" (seamless or welded)
Application & uses	Adhesives / Glue, Abrasives, Chemical Fluids, Fuels, Food & Beverages, Hydraulic Fluids, Gases, Oil / Petroleum, Medical Fluids, Pneumatic Media, Pharmaceutical Fluids, Steam, Water

Chemical Properties of EN 10216-5 Stainless Steel Pipes

Steel grade		Carbon	Phosphorus	Manganses	Silicon	Chromium	Sulfur	Nitrogen	Molybdenum	Copper	Niobium	Nickel	Titanium
Steel name	Steel number	Carbon	Phosphorus	Manganses	Silicon	Chromium	Sulfur	Nitrogen	Molybdenum	Copper	Niobium	Nickel	Titanium
X2CrNi18-9	1.4307	00.03	00.04	2.00	1.00	17.5-19.5	00.015	00.11	-	-	-	8.0-10.0	-
X2CrNi19-11	1.4306	00.03	00.040	2.00	1.00	18.0-20.0	00.015	00.11	-	-	-	10.0-12.0	-
X2CrNiN18-10	1.4311	00.030	00.040	2.00	1.00	17.0-19.50	00.015	00.12-0.22	-	-	-	8.5-11.5	-
X5CrNi18-10	1.4301	00.07	00.040	2.00	1.00	17.0-19.50	00.015	00.11	-	-	-	8.5-11.5	-
X6CrNiTi18-10	1.4541	00.08	00.040	2.00	1.00	17.0-19.00	00.015	-	-	-	-	9.0-12.0	5xC
X6CrNiNb18-10	1.4550	00.08	00.040	2.00	1.00	17.0-19.00	00.015	-	-	-	10xC-1	9.0-12.0	-
X1CrNi25-21	1.4335	00.020	00.025	2.00	00.25	24.0-26.0	00.010	00.11	00.20	-	-	20.0-22.0	-
X2CrNiMo17-12-2	1.4404	00.030	00.04	2.00	1.00	16.50-18.50	00.015	00.11	2.00-2.50	-	-	10.0-13.0	-
X5CrNiMo17-12-2	1.4401	00.07	00.040	2.00	1.00	16.50-18.50	00.015	00.11	2.0-2.5	-	-	10.0-13.0	-
X1CrNiMoN22-2	1.4466	00.020	00.025	2.00	00.70	24.0-26.0	00.010	00.1-0.16	2.0-2.5	-	-	21.0-23.0	-
X6CrNiMoTi17-12-2	1.4571	00.08	00.04	2.00	1.00	16.5-18.5	00.015	-	2.0-2.5	-	-	10.50-13.50	-
X6CrNIMoNb17-12-2	1.4580	00.08	00.040	2.00	1.00	16.5-18.5	00.015	-	2.0-2.5	-	10xC-1	10.50-13.50	-
X2CrNiMoN17-13-3	1.4429	00.030	00.040	2.00	1.00	16.5-18.5	00.015	00.12-0.22	2.50-3.0	-	-	11.0-14.0	-
X3CrNiMo17-13-3	1.4436	00.05	00.040	2.00	1.00	16.5-18.5	00.015	00.11	2.50-3.0	-	-	10.5-13.0	-
X2CrNiMo18-14-3	1.4435	00.030	00.040	2.00	1.00	17.0-19.0	00.015	00.11	2.50-3.0	-	-	12.5-15.0	-
X2CrNiMoN17-13-5	1.4439	00.030	00.040	2.00	1.00	16.5-18.5	00.015	00.12-0.22	4.00-5.00	-	-	12.5-14.5	-
X1NiCrMoCu31-27-4	1.4563	00.020	00.030	2.00	00.70	26.0-28.0	00.010	00.11	3.00-4.00	00.7-1.50	-	30.0-32.0	-
X1NiCrMoCu25-20-5	1.4539	00.02	00.030	2.00	00.70	19.0-21.0	00.010	00.15	4.00-5.00	1.2-2.00	-	24.0-26.0	-
X1NiCrMoCuN20-18-7	1.4547	00.02	00.030	1.00	00.70	19.5-20.50	00.010	00.18-0.25	6.00-7.00	00.5-1.00	-	17.5-18.5	-
X1NiCrMoCuN25-20-7	1.4529	00.020	00.030	1.00	00.50	19.0-21.0	00.010	00.15-0.25	6.00-7.00	00.5-1.50	-	24.0-26.0	-
X2NiCrAlTi32-20	1.4558	00.030	00.020	1.00	00.70	20.0-23.0	00.015	-	-	-	-	32.0-35.0	8x(C+N)0.60

Mechanical Properties of EN 10216-5 Stainless Steel Pipes

SS	Tensile Stress (MPa) min	Min Yield Strength 0.2% Proof (MPa)	Min Elongation (% in 50mm)	Hardness Value
SS	Tensile Stress (MPa) min	Min Yield Strength 0.2% Proof (MPa)	Min Elongation (% in 50mm)	(HR B) Rockwell B max	(HB) Brinell max
304	515	205	40	92	201
304L	485	170	40	92	201
304H	515	205	40	92	201
304H Stainless Steel also has a requirement for a grain size of ASTM No 7 or coarser.

Equivalent Grade of EN 10216-5 Stainless Steel Pipes

EN Standards	Material number	DIN	Tube Test class	Steel
10216-5	X2CrNiMoN22-5-3	1.4462	TC2	Duplex
10216-5	X5CrNi18-10	1.4301	TC2 / TC1	SS 304
10216-5	X6CrNiMoTi17-12-2	1.4571	TC2	SS 316Ti
10216-5	X1NiCrMoCu25-20-5	1.4539	TC2	Superaustenitic
10216-5	X2CrNi19-10	1.4306	TC2 / TC1	304L/ Seamless
10216-5	X5CrNiMo17-12-2	1.4401	TC2 / TC1	SS 316
10216-5	X2CrNiMo17-12-2	1.4404	TC2 / TC1	SS 316L
10216-5	X6CrNiTi18-10	1.4541	TC2	SS 321
10216-5	X6CrNiNb18-10	1.4550	TC1	AISI 347/ Seamless

Basic Type of EN Pipes

1.4571 EN 10216-5 Seamless Steel Tubes

1.4301 EN 10216-5 Stainless Steel Tube

1.4541 EN 10216-5 Stainless Steel Seamless Pipe

1.4462 EN 10216-5 SMLS Stainless Steel Pipe

DIN 17458 EN 10216 5 stainless steel tubes

1.4404 EN 10216-5 Stainless Steel Seamless Tubes
