DIN 2391 ST52 Pipes

DIN 2391 ST52 Pipes, DIN 2391 ST52 Pipes Manufacturers, DIN 2391 ST52 Pipes Suppliers, DIN 2391 ST52 Pipes Stockists, DIN 2391 ST52 Pipes Exporters

DIN 2391 ST52 Pipes Manufacturers In India, DIN 2391 ST52 Pipes Suppliers In India, DIN 2391 ST52 Pipes Stockists In India, DIN 2391 ST52 Pipes Exporters In India

1.0570 Steel Seamless Tube and S355 ST52 Pipe supplier in India

DIN 2391 ST52 Pipes Manufacturers in Mumbai, DIN 2391 ST52 Pipes Suppliers in Mumbai, DIN 2391 ST52 Pipes Stockists in Mumbai, DIN 2391 ST52 Pipes Exporters in Mumbai

The DIN 2448 ST 52 Rectangular Pipe is used in both mechanism as well as for irrigation & distribution of extreme cold wave, high heat & high temperature gases. However, manufacture these DIN 2448 ST 52 carbon steel pipes in the form of a straight drip and with the wall being thin, if demanded by client. Apart from having these plats, the DIN 2391 ST52 Welded Pipe can be welded without any labor because of their good weldable plats. In addition, the DIN 2391 ST 52 Square Pipe has great cold forming feature. DIN 2391 ST52 are a low carbon, manganese containing brand pipe. This carbon hung ST 52 Steel Grade Seamless Pipe produced is known to have good impact resistance. Clients belonging to demanding sectors correspondent as the construction diligence as well as general engineering diligence prefer using these ST 52 Steel Pipes either in an raw or in a homogenized condition.

DIN 2391 ST52 pipes have an Lengthening of 14 min. Because of their aspects and characteristics, 2391 ST52 pipes are used in rainbow usages resembling as food processing stuff, farming and ranch ministry, earth moving stuff, hydraulic and shapely cylinders for mining, automotive and transport lifting stuff, mechanical tools and stuff, disposal transport, hoists, compressors, waste etc. DIN 2391 ST52 pipe aspects is that of a Chemical Composition of P most0.025, C ≤0.22, Mn ≤1.6, Si ≤0.55 and S most0.025. DIN 2391 ST52 pipes have a Tensile Strength of 600 Mpa Min. The Yield Strength of DIN 2391 ST52 pipes is 520 Mpa Min.

All Chhajed products are manufactured under strict process control and monitored throughout the production process. They go through several checks to ensure that the product delivered is of finest quality!

Specification Schedule of DIN 2391 ST52 Pipes

Standard Specification	European EU EN: E355 (1.0580) USA SAE / AISI: Gr.65 Germany DIN, W. Nr.: 1.0060, E355, St52, St52-3 France AFNOR: E335, ES355, TS-47a, TU526 England BS: CEW5, CFS5, E335, ERW5NKM Italy UNI: E335, Fe510 Sweden SS: 1650 Poland PN: MSt6 Czechia CSN: 11600 Austria ONORM: St60F Russia GOST: St6sp Inter ISO: Fe590
Codes and Standards	ANSI, ASME, ASTM, API, SAE, BS, AGA, AWWA, ISO, DIN
Dimensions	ASME/ ANSI B36.10 / 19
Standard Size	1/2" NB to 36" NB (LSAW, SSAW, HSAW)
Wall Thickness	3-12mm
Pipe schedules	SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS
Producing techniques	Hydraulic cold drawn, cold rolled, Seamless / ERW / Welded / Fabricated / CDW / EFW
Available Shapes	Round, Half Round, Square, Rectangular or Custom shape
Length	3000~8000mm, Ready Length: 13M
ID Accuracy	H7, H8, H9
Surface Roughness	Ra0.4-Ra0.8
Delivery condition	BK(+C), BKW(+LC), BKS(+SR), GBK(+A), NBK(+N).
Test Certificate	EN 10204 3.1 B
Tube Tolerance	OD tolerance as per EN10305-2 or DIN2391-1
W.T tolerance	+/-3% max.

Chemical Properties of DIN 2391 ST52 Pipes

Steel Grade	Chemical Composition (%)
	C	Si	Mn	P	S	Cr
	C	Si	Mn	≤
St45	0.17-0.24	0.17-0.37	0.35-0.65	0.035	0.035	0.250
ST52 (E355)	≤0.22	≤0.55	≤1.6	0.025	0.025	0.25
SAE1026	0.22-0.28	0.15-0.35	0.60-0.90	0.040	0.050	/
27SiMn	0.24-0.32	1.10-1.40	1.10-1.40	0.035	0.035	0.300
20#	0.17-0.24	0.17-0.37	0.35-0.65	0.035	0.035	0.250

Mechanical Properties of DIN 2391 ST52 Pipes

Delivery condition	BKS Cold Drawn & Stress-Relieved
Steel Grade	Rm MPa	ReH MPa	Elongation A5(%)
ST45	≥520	≥375	≥15
ST52(E355)	≥600	≥520	≥14
SAE1026	≥600	≥510	≥15
16Mn	≥600	≥520	≥14
20#	≥520	≥375	≥15

Equivalent Standard of DIN 2391 ST52 Pipes

China steel grades: GB standard	16Mn, Q345
Germany steel grades: DIN standard	ST52, ST52.3
DIN 2391-2	1.0580 St52
Din 2393 & 2394	1.0570 St52-3
EN10025	1.0570 S355

Basic Type of DIN Pipes

DIN 2391 ST52 Steel Pipe

DIN 2448 ST 35 Round Pipe

DIN 2391 ST 35 Seamless Pipe

DIN 2391 ST52 Welded Pipe

DIN 2391 ST52 BK Hydrualic Pipe

Carbon Steel ST 52 Double wall pipe
