Duplex 2205 Pipe Fittings

Duplex 2205 Pipe Fittings, Duplex 2205 Pipe Fittings Manufacturers, Duplex 2205 Pipe Fittings Suppliers, Duplex 2205 Pipe Fittings Stockists, Duplex 2205 Pipe Fittings Exporters

Duplex 2205 Pipe Fittings Manufacturers In India, Duplex 2205 Pipe Fittings Suppliers In India, Duplex 2205 Pipe Fittings Stockists In India, Duplex 2205 Pipe Fittings Exporters In India

Duplex 2205 Pipe Fittings

Duplex 2205

Duplex 2205 Pipe Fittings Manufacturers in Mumbai, Duplex 2205 Pipe Fittings Suppliers in Mumbai, Duplex 2205 Pipe Fittings Stockists in Mumbai, Duplex 2205 Pipe Fittings Exporters in Mumbai

We, Chhajed Steel Limited are duplex fittings stockist and supplier. It is been manufactured by premium raw material. We offer these fittings in different size, shape, dimensions, thickness and length. Duplex 2205 pipe fittings are two-phase, ferritic and austenitic it contains chromium of 22%, molybdenum of 3%, nickel 5 to 6%. It is widely used and is characterized by high yield strength double that of the standard austenitic stainless steel grades.

Duplex Reducer is used in process piping that reduces the pipe size from a larger bore to a smaller bore It allows for a change in pipe size to meet hydraulic flow requirements of the system, or to change existing piping of a different size. It is superior to standard austenitics with regard to stress corrosion cracking resistance.

All Chhajed products are manufactured under strict process control and monitored throughout the production process. They go through several checks to ensure that the product delivered is of finest quality!

Specification Schedule of Duplex 2205 Pipe Fittings

Duplex 2205 Fittings Dimensions ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10
ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Duplex 2205 Pipe Fittings size Seamless Duplex 2205 Stainless Butt Weld Fittings: 1/2" - 10"
Welded 2205 Stainless Steel Butt Weld Fittings: 1/2" - 48"
Specifications ASTM A815 / ASME SA815
Duplex 2205 Fittings Thickness SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75
Duplex 2205 Forged Fittings Thread NPT, BSPT, BSPP
ASTM A815 Fittings Type DN15-DN1200
Duplex 2205 Pipe Fittings Types Seamless / ERW / Welded / Fabricated Duplex 2205 Werkstoff 1.4462 Pipe Fittings Manufacturer and supplier
Fitting Duplex 2205 Connection Welding
Bending Radius R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom Avesta 2205 Pipe Fittings
Duplex 2205 Forged Fittings Pressure Rating Threaded end-2000lb/ 3000lb/ 6000lbs Duplex 2205 1.4462 Pipe Fittings
Socket-weld end-3000/ 6000/ 9000lbs Duplex 2205 Stainless Steel Pipe Fittings
Fitting Duplex 2205 Size Range 1/2" NB to 24" NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100)
Duplex 2205 F51 Pipe Fittings Manufacturing process Push, Press, Forge, Cast, etc.
Key markets and industries for 22cr Fitting Duplex 2205
  • Bitumen upgraders.
  • Heavy oil refineries.
  • Nuclear power (mostly seamless).
  • Petrochemicals and acids.
Duplex 2205 Elbow Angle : 22.5 deg, 30deg, 45 deg, 90 deg, 180 deg, 1.0D, 1.5D, 2.0D, 2.5D, 3D, 4D, 5D, 6D, 7D-40D.
Standard: ASME B16.9, ASME B16.28, ASME B16.25, MSS SP-75 DIN2605 JISB2311 JISB2312 JISB2313, BS, GB, ISO
Specialized manufacturer of 90º Elbows, 45º Elbows, Tees, Crosses, Equal Tees & Reducing Tees,Couplings, Reducers, Inserts, Unions, Caps, Nipples, Forged Pipe Fittings, Socket Weld & Threaded, 90° & 45° Elbows - Female-Female, Male-Male, Male-Female, Union, Nipples, Couplings, Plugs Fittings Manufacturer and supplier
Duplex 2205 Pipe Fittings Test Certificates EN 10204/3.1B
Raw Materials Certificate
100% Radiography Test Report
Third Party Inspection Report, etc
SA815 Material End
  • Beveled
  • plain
  • Grooved
  • Threaded
  • Welding
  • JIC
F51 Duplex 2205 Pipe Fittings uses & application
  • Fittings To Connect Pipe & Tubes in Petroleum, Power, Chemical, Construction, Gas, Metallurgy, Shipbuilding etc
  • Schedule 10 Duplex 2205 Stainless fittings are an economical alternative for lower-pressure applications.
  • Schedule 40 2205 Stainless Steel fittings have a thicker wall for higher-pressure applications.
Material Test Certificates (MTC) for Duplex 2205 Fittings as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175

Chemical Properties of Duplex 2205 Pipe Fittings

Duplex 2205 C Mn Cr Fe N Si P S Mo Ni
ASTM A276 S31803 0.030 max 2.00 max 22.0 – 23.0 63.72 min 0.14 – 0.20 1.00 max 0.030 max 0.020 max 3.0 – 3.5 4.50 – 6.50
ASTM A276 S32205 0.030 max 2.00 max 21.0 – 23.0 63.54 min 0.8 – 0.20 1.00 max 0.030 max 0.020 max 2.5 – 3.5 4.50 – 6.50

Mechanical Properties of Duplex 2205 Pipe Fittings

Density 7.8 g/cm3
Tensile Strength (PSI/MPa) Psi - 90000 , MPa - 620
Yield Strength (PSI/MPa) (0.2%Offset) Psi - 65000 , MPa - 450
Melting Range 1440 °C (2625 °F)
Elongation % 30 %

Equivalent Standard of Duplex 2205 Pipe Fittings

GRADE WERKSTOFF NR./ DIN UNS ASTM ASME
Duplex Steel 2205 1.4462 S31803 / S32205 A276 SA 276

Basic Type of Duplex Pipe Fittings

Duplex Steel Pipe Fittings

Duplex 2205 Pipe Fittings

Duplex Steel Pipe Fittings

Duplex 2205 Pipe Fittings

Duplex Steel Pipe Fittings

ANSI Duplex SS Pipe Fittings

Duplex Steel Pipe Fittings

ASME B16.5 Duplex Buttweld Fittings

Duplex Steel Pipe Fittings

ASTM A815 Duplex Pipe Fittings

Duplex Steel Pipe Fittings

ANSI B16.5 Duplex Stainless Steel Pipe Fittings

Duplex Steel Pipe Fittings

Duplex 2205 SS Concentric Reducer

Duplex Steel Pipe Fittings

ASME B16.5 Duplex SS 90 Degree Elbow

Duplex Steel Pipe Fittings

45/90/180 Degree Duplex Stainless Steel Pipe Fittings
